Portfolio Archives: Coil Manufacturing

You are here:
  1. Home
  2. Project
ZoomDetails

Packing

Coil ManufacturingBy occ-adminMay 21, 2020Leave a comment

Every coil is packed by following stringent packing methods to ensure no damages happen during transit.

ZoomDetails

Sheet Metal – Casing Work

Coil ManufacturingBy occ-adminMay 21, 2020Leave a comment

For all casing work i.e. Endplate, side-plate, Intermediate support plates , this Japanese machine makes sure it very much precise through CNC operation.

ZoomDetails

Anti-Corrosive Coating

Coil ManufacturingBy occ-adminMay 21, 2020738 Comments

As per requirement coils are coated using spray/dip application for anti-corrosive coatings.

ZoomDetails

Brazing & Assembly

Coil ManufacturingBy occ-adminMay 21, 2020Leave a comment

All coils are brazed either manually or on the automatic brazing machine using latest technology to make the process faster.

ZoomDetails

Internal View of Factory

Coil ManufacturingBy occ-adminApril 22, 2020Leave a comment

3000 Sq. mtr factory area encompassing latest machinery for producing high quality customized HVAC coils.

ZoomDetails

Finning

Coil ManufacturingBy occ-adminApril 7, 2020

Fining is done on state of the art American machines & can fin with Plain Aluminium, Pre-coated / Hydrophylic Aluminium & copper fins.

ZoomDetails

Tube Cutting [Straight cut to length]

Coil ManufacturingBy occ-adminMarch 29, 2020

Fully automatic American straight cut to length machine makes the LWC copper pipes to cut in desired lengths.

ZoomDetails

Hair Pin Bending

Coil ManufacturingBy occ-adminMarch 23, 2020

This American machine eliminates the use of return bend on one side of all coils for 3/8” OD & ½” OD tubes.

ZoomDetails

Expansion

Coil ManufacturingBy occ-adminMarch 6, 2020

All coils are expanded using bullet expansion & for coils less than 1400 mm long, the vertical expander is used to ensure firm bonding between tube & fins.

ZoomDetails

Coil Bending

Coil ManufacturingBy occ-adminMarch 6, 2020

For bend coils, specialized bending machine is used to achieve desired bending radius.

12
